82
Chapter 4
TYPICAL WASTE SYSTEM-VACUUM STYLE MODELS
1. Toilet Bowl
2. Solenoid Valve
3. Fresh Water Pressure Pump
4. System Vent
5. Holding Tank
6. Fresh Water Tank (System can also run from dockside
water supply)
5
6
Forward Head
Aft Head
To 12 Volt Main
Control Panel
Fwd. Head Breaker
To 12 Volt Main
Control Panel Aft
Head Breaker
To 12 Volt Main
Control Panel
Fresh Water
Pressure Pump
Breaker
Wall Control Panel
