28
Chapter 7
HATCH-ENGINE
The engine hatch
provides easy access
for periodic bilge and
equipment inspections.
The engine compart-
ment (bilge) lights can
be accessed at the aft
port exterior lighting
panel.
The engine hatch lift switch is also found on this panel.
Since the hatch is electric and forward facing it is easiest
to access the engine compartment from the aft to check
engines, drive units and generator fl uids.
The engine hatch uses a single heavy duty electric-hydraulic
ram to operate up and down. Should the need arise there
is a top pin which can be pulled to permit the hatch to be
lifted manually in case of emergencies.
Note: Manually lifting the engine hatch requires additional
manpower and the proper blocking to hold the hatch up.
Do not attempt this procedure alone.
Removable
Hatch Pin
Typical Hatch
Ram
Actuator
