7
Auxiliary Equipment Operation
To change a hanging locker light bulb follow these steps:
n Remove the lens cover from the lamp base. There is a
tab on the bottom of the lens cover. Push the lens cover
at this point to remove it.
n Remove the defective bulb.
n Replace the bulb with a 12 volt halogen bulb type
# 563.
n Reinstall the lens cover by snapping it in place.
HANGING LOCKER LIGHTS-TYPICAL
READING LIGHTS-TYPICAL
Lens Cover Removed
Notched Area Here
Under Cover
LATER STYLE
The reading lights use a
marine type bulb that al-
lows for rough service.
To change the bulb turn
the fi xture and grasp
the old bulb and pull it
straight out. Replace with
the same wattage bulb.
Reinstall the bulb in the
lamp socket using a tissue
to hold it. This procedure
will help extend the bulb service life.
