TYPICAL BATTERY MANAGEMENT SYSTEM-PARTS DESCRIPTION
BREAKER CLUSTERS
DIGITAL VOLTAGE
SENSITIVE RELAY
DIGITAL
VOLTAGE
SENSITIVE
RELAY
HOUSE BATTERY
SWITCH
PORT/STBD. ENGINE
BATTERY SWITCH
MAIN CIRCUIT
DC BREAKER CLUSTER
COMBINE BATTERIES
(AT ARROW) FOR
EMERGENCY STARTS
