TYPICAL 12 VOLT HELM BREAKER PANEL DESCRIPTION
HORN- protects the horn circuitry.
SPOT LT- protects the deck mounted spot/search
light.
TRIM TABS- protects the transom mounted electric-
hydraulic trim tab circuit.
NAV LTS- protects the port and starboard deck naviga-
tion for night cruising.
COCKPIT LTS.- protects the cockpit installed light cir-
cuit.
HIGH WATER ALARM- protects the helm mounted
alarm. Part of the system including the sensor fl oat is
located in the engine room.
WIPER- protects windshield wiper circuit.
WINDLASS- protects the deck mounted foot petals.
EXHAUST- protects the head exhaust blower.
VAPOR DETECT- If installed protects the gas vapor
detector circuitry on gasoline powered propulsion.
BLOWER 1- protects the port powered engine ventila-
tion circuitry.
BLOWER 2- protects the starboard powered engine
ventilation circuitry.
BILGE LTS.- protects the lights in the engine room.
12 VOLT RECEPTACLE- protects the helm mounted
equipment outlet.
UNDERWATER LTS.- protects the transom mounted
light (under platform) circuit.
HALON INDICATOR.- protects the halon fi re extin-
guisher system.
DOCKING LTS- protects the docking light circuitry.
HATCH LIFT- protects the hatch actuator component
circuitry.
AFT BILGE PUMP- protects the bilge pump located
aft in the engine room.
FWD. BILGE PUMP- protects the forward bilge pump
circuitry.
ACCESSORY (FUSE)- protects the optional hydraulic
swim platform circuit.
VHF RADIO (FUSE)- protects the marine radio cir-
cuitry.
GPS (FUSE)- protects the GPS chartplotter circuitry.
NMEA (FUSE)- protects NMEA 2000 network.
