41
Systems
TYPICAL 12 VOLT HELM SWITCH PANEL DESCRIPTION
ARCH- activates the radar arch dual actuator system
which drives the hydraulic rams to raise and lower arch.
ELECTRONICS- controls any electronics installed in-
cluding chartplotter and radar.
UNDER WATER LTS- energizes the optional transom
mounted under water lighting system.
EXHAUST- activates the optional Corsia engine exhaust
sytem.
ACC- controls the optional hydraulic swim platform.
HORN- this toggle switch signals the bow integrated
horn system blasts as needed.
NAV/ANC- energizes the bow navigation lights and the
all around light.
WIPER- activates the windshield wiper on the driver’s
side.
DOCK LIGHTS- controls the optional hull docking
lights used for night maneuvering and docking.
COCKPIT LTS- activates the LED cockpit lights in-
stalled on the deck.
