RENA XPS-80/90
User Guide
5-8
5.4 Identifying print media dimensions
The maximum dimensions of the print media are:
Height
(measured 90 degrees to transport direction): 355mm (13.97“)
Width
(measured in the direction of transport): 420mm (16.53“)
The transport area can handle up-to a maximum height of
355mm, as shown in the diagram below. If the print media is
larger or if it is positioned so there is less than a 22.5mm mar-
gin, on each side of the transport area, paper jams may occur.
Max. width 420mm
Max. height
355mm
22.5mm
Tranport Direction
