RENA XPS-80/90
User Guide
6-14
6.4 Special function submenus
This menu section comprises special functions, which change the
operation of the printer.
16.1 Character spacing
Spacing between the characters 0 - 90 dots.
16.2 Character height
Height of the characters 1x
, 2x to 6x. (Up to a max of 48 points.)
16.3 Character width
Width of the characters 1x, 2x to 6x
16.4 Line spacing
Line spacing 1 ... 6 ... 10 dots per inch (dpi).
16.5 Hex to ASCII
on, off
When set to “on” a “%“ symbol is seen as a prefix (trigger), to in-
terpret and use the following two characters as their HEX value.
16.6 Capping delay (XPS-90)
Delays the print units return to their parking position after printing.
Settings: off
, 10 sec., 20 sec. 30 sec. 40 sec., 50 sec. and 60 sec.
