AIR VENTS (continued)
Air flow
Move the control knob 1 or 3 (beyond
the resistance point).
o: maximum air flow.
z: closed.
Direction
Right/left: move tabs 2 or 4.
Up/down: lower or raise tabs 2 or 4.
1
2
2
3
4
To remove bad odours from your ve-
hicles, only use the systems designed
for this purpose. Consult an approved
Dealer.
Do not add anything to the
vehicle’s ventilation circuit
(for example, to remove
bad odours).
There is a risk of damage or of
fire.
