bonnet...................................................(up to the end of the DU)
4.2
ENG_UD22615_4
Capot moteur (X77 ph2 - Renault)ENG_NU_815-9_X77_Renault_4
Jaune Noir Noir texte
Bonnet
BONNET (1/2)
To open the bonnet, pull the handle 1.
Unlocking the bonnet catch
To open, push tab 2 to the left as you
open the bonnet.
Before opening the bonnet,
remember to return the
windscreen wiper stalk to
park position (refer to the in-
formation on the “Windscreen wash/
wipe” in Section 1).
2
1
The engine may be hot
when carrying out opera-
tions in close proximity. In
addition, the engine cooling
fan can come on at any moment.
Risk of injury.
In the event of even a slight
impact involving the radia-
tor grille or bonnet, have
the bonnet lock checked by
an approved dealer as soon as pos-
sible.
Opening the bonnet
Lift the bonnet and release stay 4 from
its holder 5. For your own safety, it is
very important to fix the stay into re-
tainer 3 in the bonnet.
3
4
5
