Aménagement coffre à bagage
LUGGAGE COMPARTMENT FITTINGS
Location for anchorage
points
On equipped vehicles, these are for se-
curing items transported in the luggage
compartment (refer to the information
on “Transporting objects in the luggage
compartment”).
Depending on the vehicle, a net for re-
taining luggage on the floor, located
in the storage compartment under the
passenger seat, may be attached to
these hooks.
1
1
Strap
Depending on the vehicle, this strap is
used to hold a bottle, etc.
2
Luggage compartment hook
3
On equipped vehicles, there may be up
to three of these in the luggage com-
partment. These hooks can be used to
hold a bag, etc.
3
