CHILD SAFETY: Choosing a child seat mounting (continued)
The two rings 1 are located between
the seatback and the seat base of the
seat and are identified by a marking.
To ensure your child seat can be easily
fitted and locked on rings 1, use access
guides 2 on the child seat.
The ISOFIX anchorage
points have been exclu-
sively designed for child
seats with the ISOFIX
system. Never fit a different type of
child seat, seat belt or other objects
to these fittings.
Check that nothing is obstructing
the anchorage points.
If your vehicle has been involved in
a road accident, have the ISOFIX
fittings checked and replace your
child seat.
5
4
3
The 3
rd
ring is used to attach the upper
belt on some child seats.
Depending on the vehicle, to attach the
child seat belt 3:
– open the ring cover 5,
– attach the hook 4 to the ring 5 lo-
cated on the roof rear cross member
and marked by
±,
– close the cover and tighten the belt.
Do not change the position of the bench
seat (if sliding) after tensioning the belt.
1
2
