Renesas RA Family EK-RA4E2 v1 – User's Manual
R20UT5175EG0300 Rev. 3.00 Page 5 of 30
Feb.27.23
Breakout Pin
Header J2
Breakout Pin
Header J3
Debug LED and
USB Connector
Debug (JTAG/SWD)
Connectors
Pmod 2
Connector
+3.3 V Test Points
mikroBus
Connector
Grove and Qwiic
Connectors
+5 V Test Points
Pmod 1
Connector
Reset Switch
User Switches
User LEDs
MCU Current
Measurement Points
Breakout Pin
Header J1
RA4E2 MCU
MCU USB Current
Measurement Points
USB Full Speed
CAN Bus
Power
Regulation
Arduino Uno Connectors
(Analog and Power)
Arduino Uno
Connectors (Digital)
MCU Clock Crystals/
Select
Figure 1. EK-RA4E2 Board Top Side
