2. Power Supply
2.1 Requirements
This board has a USB Type-C connector (CN5) and an optional centre positive supply connector using a
2.0mm barrel power jack (CN6). Supply power to the CPU board from either CN5 or CN6.
The main power supply connected to CN6 should supply a minimum of 15W to ensure full functionality.
This CPU board supports two external voltage input. Details of the external power supply connection are
shown in Table 2-1 below.
Table 2-1: Main Power Supply Requirements
Connector
Supply voltage
CN5 Type-C VBUS (5VDC)
CN6
Input 5VDC*
*: There are RSK+ products which require a 12V voltage input. Since this board requires a 5V voltage input, be careful not
to connect the power supply of a high-voltage output accidentally. Moreover, the main power supply connected to CN6
should supply a minimum of 15W to ensure full functionality.
