6.3 MPU Operating Modes
Table 6-3 and Table 6-4 and Table 6-5 below details the option links associated with configuring the MPU
Operating Modes.
Table 6-3: MPU Operating Modes Switch Settings (1)
SW4-1
(MD0)
SW4-2
(MD1)
SW4-3
(MD2)
Explanation
ON
ON
ON
xSPI0 boot mode (x1 boot Serial flash)
OFF
ON
ON
xSPI0 boot mode (x8 boot Serial flash) *
1
ON
OFF
ON
16-bit bus boot mode (NOR flash)
OFF
OFF
ON
32-bit bus boot mode (NOR flash) *
1
ON
ON
OFF
xSPI1 boot mode (x1 boot Serial flash) *
1
OFF
ON
OFF
SCI (UART) boot mode
ON
OFF
OFF
USB boot mode
OFF
OFF
OFF
Reserved (setting prohibited)
*
1
: Not supported on this board.
Table 6-4: MPU Operating Modes Switch Settings (2)
SW4-4
(MDD)
Explanation
ON
JTAG Authentication by Hash is disabled.
OFF
JTAG Authentication by Hash mode
Table 6-5: MPU Operating Modes Switch Settings (3)
SW4-5
(MDW)
Explanation
ON
ACTM 0 wait
Valid for CPU operating frequency equal to or less than 400MHz
OFF
ACTM 1 wait
