6.16 IRQ & Switch Configuration
Table 6-47, Table 6-48, Table 6-49 below details the function of the option links associated with IRQ & Switch
Configuration.
Table 6-47: IRQ & Switch Configuration Option Links (1)
Signal name
MPU
MPU Peripheral Selection
Destination Selection
Pin
Port
Signal Fit DNF
Interface
/Function
Fit DNF
BSC_A01_CAN_TX P2 P05_3
BSC_A01
IC29.56
(SW6-1 = ON)
-
IC22.E1
-
-
IC23.23
-
-
JA3-A.2
-
-
CAN_TX
IC29.55
(SW6-1 = OFF)
-
CN1.18
-
-
JA5-A.5
-
-
U10.1
-
-
BSC_A16_M2_ENCZ J5 P02_2 BSC_A16
IC29.25
(SW6-1 = ON)
-
IC22.B8
-
-
JA3-A.37
BSC_A02_CAN_RX P3 P05_2
BSC_A02
IC29.2
(SW6-1 = ON)
-
IC22.D1
-
-
IC23.24
-
-
JA3-A.3
-
-
CAN_RX
IC29.3
(SW6-1 = OFF)
- CN1.17 - -
CAN_RX_JA5
IC29.3
(SW6-1 = OFF),
SW6-9 =ON
SW6-10 = OFF JA5-A.6 - -
CAN_RX_OB
IC29.3
(SW6-1 = OFF),
SW6-10 = ON
SW6-9 = OFF U10.4 - -
ETH2_INT#
G6
P00_4
ETH2_INT#
-
-
IC16.51
-
-
ETH1_INT#
R2
P05_6
ETH1_INT#
-
-
IC31.51
-
-
IRQ11_ENCIF9_WAIT# K3 P03_3 IRQ11_ENCIF9_WAIT# - -
J22.2
-
-
CN1.12
-
-
JA3-A.45
-
-
ETH0_LINK
R11
P10_4
ETH0_LINK
IC36.4
-
IC35.59
-
-
P18_1 G19 P18_1
SCI_RTS
SW5-3 = ON
SW5-4 = OFF
J25.4
-
-
M1_UN
SW5-4 = ON
SW5-3 = OFF
JA2-A.14
-
-
IRQ9
H20
P17_2
IRQ9
-
-
J26.7
-
-
BSC_A11_M1_UP L3 P03_6
BSC_A11
IC29.39
(SW6-1 = ON)
-
IC22.D6
-
-
IC23.22
-
-
JA3-A.12
-
-
M1_UP
IC29.38
(SW6-1 = OFF)
SW5-10 = OFF
CN3.14
-
-
JA2-A.13
BSC_A12_M1_TOG K2 P03_5
BSC_A12
IC29.19
(SW6-1 = ON)
-
IC22.A7
-
-
IC23.35
-
-
JA3-A.13
-
-
M1_TOG
IC29.20
(SW6-1 = OFF)
- JA6.13 - -
DIP_SW6_18
P16
P13_2
DIP_SW6_18
SW3.6 = OFF
-
SW3.6
-
-
IRQ3 D19 P19_2 IRQ3 - -
J25.7
-
-
JA1-A.23
-
-
P18_3 G18 P18_3
MB_RST#
SW6-8 = ON
SW6-7 = OFF
J21.2
-
-
M1_WN
SW6-7 = ON
SW6-8 = OFF
JA2-A.18
-
-
ETH0_INT#
Y5
P09_2
ETH0_INT#
-
-
IC35.51
-
-
NMI_18
L19
P16_2
NMI_18
-
-
NMI
E32
-
SW1
T13
P10_5
SW1
-
-
SW1
-
-
SW2
K16
P16_3
SW2
-
-
SW2
-
-
