LS350 laser beam steering optic
The laser steering optic is an alignment aid for the XL laser system. The device
allows for easy adjustment in the vertical and horizontal plane of the laser beam
and reduces the amount of adjustment to be made at the laser head using the
tripod stage.
The steerer can be used with the following optics:
• Linear optics
• Linear/angular combination kit
• Angular optics
• Straightness optics
• Fixed turning mirror
• Swivel mirror
• Optical square (in conjunction with fixed turning mirror)
Long range linear accessory kit
The long range large retro-reflector and periscope returns the measurement beam
from the periscope back to the laser at the correct displacement to enter the laser
detector port. This is designed for measurements up to 80 m.
1
Long range large retroreflector
2
Periscope beam-splitter
3
Target
4
Clamp screws
1
4
2
3
