Renishaw XL Series User Manual

37
XL laser system
XL-80 hardware XL-80 applications
Index Part number Part name Includes Part number (qty 1) Index
1
A-9908-0405 XL-80 laser kit
XL-80 laser 1A
Universal power supply A-9908-0299 1B
USB cable A-9908-0286 1C
Laser software kit A-9908-0201 not shown
AUX/I/O connector A-9908-0329 not shown
2
A-9908-0700 Tripod stage kit
XL tripod stage 2A
Spirit level circular A-9908-0323 2B
XL tripod stage adaptor A-9908-0770 not shown, tted to tripod
3
A-9908-0510 XC-80 compensator kit
XC-80 compensator 3A
Material temperature sensor & cable A-9908-0879 3B
Air temperature sensor & cable A-9908-0878 3C
XC mounting plate A-9908-0892 3D
USB cable A-9908-0286 3E
4
A-8003-0440 Linear measurement optics
Linear reector (qty 2) A-8003-0219 4A
Linear interferometer A-8003-0557 4B
Alignment target (qty 2) A-8003-0478 4C
5
A-8003-0441 Angular measurement optics
Angular reector A-8003-0181 5A
Angular interferometer A-8003-0186 5B
Alignment target (qty 2) A-8003-0478 5C
6
A-8003-0443 Straightness optics - short range (0-4 m)
Short range straightness reector A-8003-0615 6A
Wollaston short range A-8003-0393 6B
7
A-8003-0444 Straightness optics - long range (1-30 m)
Long range straightness reector A-8003-0620 7A
Wollaston long range A-8003-0430 7B
8
A-8003-0665 Squareness measurement optics
Optical square 8A
Bracket squareness optic M-8003-1680 8B
Cap head screw (qty 4) 8C
Hexagonal key 8E
9
A-8003-0442 Flatness measurement kit
Flatness mirror (qty 2) A-8003-0630 9A
Base (150 mm) A-8003-0256 9B
Base (100 mm) A-8003-0257 9C
Base (50 mm) A-8003-0258 9D
Full XL system contents

Renishaw XL Series Specifications

General

Laser Wavelength	633 nm
Type	Laser interferometer
Measurement Range	Up to 80 meters
Accuracy	±0.5 ppm
Environmental Compensation	Automatic
Laser Source	HeNe laser
Interface	USB
Power Supply	External power supply unit
