Renishaw XL Series User Manual

40
XL laser system
XL-80 hardware XL-80 applications
Index Part number Part name Includes Part number (qty 1) Index
1
A-9908-0405 XL-80 laser kit
XL-80 laser 1A
Universal power supply A-9908-0299 1B
USB cable A-9908-0286 1C
Laser software kit A-9908-0201 not shown
AUX I/O connector A-9908-0329 not shown
2
A-9908-0700 Tripod stage kit
XL tripod stage 2A
Spirit level circular A-9908-0323 2B
XL tripod stage adaptor A-9908-0770 not shown, tted to tripod
3
A-9908-0510 XC-80 compensator kit
XC-80 compensator 3A
Material temperature sensor and cable A-9908-0879 3B
Air temperature sensor and cable A-9908-0878 3C
XC mounting plate A-9908-0892 3D
USB cable A-9908-0286 3E
4
A-8003-0440 Linear measurement optics
Linear reector (qty 2) A-8003-0219 4A
Linear interferometer A-8003-0557 4B
Alignment target (qty 2) A-8003-0478 4C
5
A-8003-0441 Angular measurement optics
Angular interferometer A-8003-0186 5A
Angular reector A-8003-0181 5B
Alignment target (qty 2) A-8003-0478 5C
6
A-8003-0447 Optics mounting kit
Clamp block (qty 2) A-8003-0262 6A
Base plate (qty 2) A-8003-0522 6B
Mounting pillar (qty 3) M-8003-0470 6C
M8 adaptor A-8003-0979 6D
7
A-8003-3072 Laser beam steerer 7
8
A-8003-1325 Fixed turning mirror 8
9
A-9908-0780 Magnetic base 9
10
A-9908-0760 XL magnetic base adaptor 10
Base XL system case contents

Renishaw XL Series Specifications

General

Laser Wavelength	633 nm
Type	Laser interferometer
Measurement Range	Up to 80 meters
Accuracy	±0.5 ppm
Environmental Compensation	Automatic
Laser Source	HeNe laser
Interface	USB
Power Supply	External power supply unit
