XL laser system
XL-80 hardware XL-80 applications
Specifications
System storage
Storage temperature range -25 °C to 70 °C
Storage humidity range 0% to 95% non-condensing
Storage pressure range 650 mbar to 1150 mbar
Power supply unit
Input voltage 100 to 240 V ±10%
Input frequency 47 to 63 Hz
Output voltage 24 V ±2%
Maximum output current 1.5 A
Safety standard EN (IEC) 60950
USB (A-B) data cable
Shielded USB2 Full or high speed
For cable length less than 3 m 28 AWG/2C (for data) 24 AWG/2C (for power)
For cable length greater than 3 m 28 AWG/2C (for data) 20 AWG/2C (for power)
Mounting stage and laser - alignment adjustment
Pitch range ±1.5 degrees
Yaw range ±1.5 degrees
Horizontal translation range 72 mm
Tripod
Positioning height range of laser when mounted on top of tripod 0.5 to 1.5 m
Collapsed length 0.64 m
Weight 3.8 kg

Renishaw XL Series Specifications

General

Laser Wavelength	633 nm
Type	Laser interferometer
Measurement Range	Up to 80 meters
Accuracy	±0.5 ppm
Environmental Compensation	Automatic
Laser Source	HeNe laser
Interface	USB
Power Supply	External power supply unit
