Renkforce 2203406 - C) Outdoor Sensor

50
c) Outdoor Sensor
23
24
25 27 28
29
30
31 32 33
34
26
23 Wind Vane
24 Wind speed sensor
25 Antenna
26 UV / Light sensor
27 Solar panel
28 Bubble level
29 Rain collector
30 Thermo-hygro sensor
31 U-Bolt
32 Battery compartment
33 Reset button
34 LED Indicator: light will turn on for 4s when the unit
ispoweredup.Thenthe LEDwillashonceevery
48 seconds (the sensor transmission update period).
