Renkforce 2203406 - E) Minimum;Maximum Mode

68
• To switch the alarm (or the alarm time) on or off, push the "SET" (5) button with the currently selected alarm.
When the alarm is activated, a bell icon " " is displayed at the lower right.
 Toleavethesettingmodeinanyplace,brieypushthebutton"HISTORY"(7). The settings made are
saved.
Alternatively, wait for 30 seconds without pushing a button. Setting mode is ended automatically in this
case.
• When an alarm is triggered (exceeding of a threshold at "HIGH ALARM", undercutting of a threshold at "LOW
ALARM" or at the alarm time), the base station will emit a sound signal and the bell icon " "ashes.Thecor-
responding text message appears at the bottom of the display.
• Push any button to end the sound signal. If the measured value remains above or below the set threshold, the bell
icon " "willcontinuetoash,however.
e) Minimum/Maximum mode
In this mode, you can have the saved minimum and maximum values displayed.
• Thebasestationmustbeinnormalmode.Nowbrieypushthe"MIN/MAX"(8) button to start the minimum/maxi-
mum alarm.
• The two lower text lines show "TODAY MAX".
 Toleavetheminimum/maximummodeinanyplace,brieypushthebutton"HISTORY"(7).
Alternatively, wait for 30 seconds without pushing a button. Minimum/maximum mode is ended automati-
cally in this case.
• Brieypushthebutton"MIN/MAX"(8) repeatedly to switch between the following 4 functions:
"TODAY MAX" Maximum values of the current day
"HISTORY MAX" Maximum values since the last reset
"TODAY MIN" Minimum values of the current day
"HISTORY MIN" Minimum values since the last reset
• Use the " " (3) or " " (4) button to call the time and date of occurrence in sequence for every minimum or
maximum value.
• Every minimum/maximum value can be deleted/reset by keeping the "SET" button pushed for 2 seconds.
