REOVIB MFS 368
Operating instructions
14
6.0 Possible settings
No. Icon Menu item Meaning Setting Factory
setting
1
P
Output
1.1 Feeder Feed rate 0...100%
0%
1.1.1 Fine
Setpoint "Fine" (previously "Activate
coarse / fine")
0...100%
0%
2 Feeder
2.1 Frequency Set frequency 35...140 Hz 100 Hz
2.2 Invert Enable Invert Enable switched Off
2.3 External setpoint Activate external setpoint switched Off
2.3.1 Setpoint Setpoint type 0/2/1...10 V / 0/4...20 mA
0/2/1...10 V /
0/4...20 mA
0...10 V
2.4 Soft start Set soft start time (setpoint 0...100 %) 0...60 sec. 1 sec.
2.5 Rundown Set soft stop time (setpoint 100...0 %) 0...60 sec. 0.1 sec.
2.6 Max. Limit maximum feed rate 0...100% 90%
2.7 Acc. controller
Activate Acc. controller (switch-off
deactivates Auto. freq.)
switched Off
2.7.1 Prop. gain Adjust P setting of Acc. controller 0.01...100 0.40
2.7.2 Integral Adjust I portion of Acc. controller
0.01...100
sec.
0.15 sec.
2.7.3 Auto. freq.
Activate frequency search and
frequency tracking (only if Acc.
controller is activated)
switched Off
2.8 Air jet present*
1
Activate air blow function switched Off
2.8.1 Air lead time*
1
Air blow lead time 0...60 sec. 0 sec.
2.8.2 Air delay time*
1
Blowing air shut-off delay 0...60 sec. 4 sec.
2.9 Hopper cycle Feeder output is cycled switched Off
2.9.1 Time On Hopper On time 0...60 sec. 15 sec.
2.9.2 Time Off Hopper Off time 0...60 sec. 4 sec.
3 Track control
3.1 Coarse / Fine Coarse / Fine switched Off
3.2 T-On Switch-on time delay 0...60 sec. 5 sec.
3.3 T-Off Switch-off time delay 0...60 sec. 5 sec.
3.4 Timeout On Activate sensor timeout switched Off
3.5 Timeout Set sensor timeout time 1...240 sec. 180 sec.
3.6 Inv. sensor Invert sensor switched Off
4
100
Limit values
4.1 Actual current Actual current display View only
4.2 Current limit*
3
Current limit 5...100% 100%
4.3 El. fuse*
3
Output switch-off, instead of output
current limitation
switched Off
4.4 Min. freq.*
3
Set minimum frequency 20...140 Hz*
2
35 Hz
4.5 Max. freq.*
3
Set maximum frequency 20...140 Hz*
2
140 Hz
4.6 Umax*
3
Output voltage limiting
230 V coil -> Umax: 100%
115 V coil -> Umax: 50%
0...100%
100%
5
In
terface
5.1 Bus operation Activate / deactivate bus mode Switched Off*
4
5.2 Bus address Internal bus address (do not change) 1...16 1
5.3 Bit rate Internal bus bit rate (do not change)
1 Mbit/s / 500
kbit/s
1 Mbit/s
5.4 Protocol Interface protocol (do not change) V1.i / V2.f V1.i
