REPLIGEN KrosFlo ACSS-60K

KrosFlo® TFF System – Auxiliary Scale ACSS-60K
User Guide
19
repligen.com 420-14871-002 Rev. 00
Table 6. Calibration report variable list
Submenu Name Description
6.1.1.
CtP
Calibration type
6.1.2.
dAt
Calibration date
6.1.3.
tin
Calibration time
6.1.4.
Idb
Scale serial number
6.1.5.
CdF
Difference between mass of a calibration weight measured during the last
calibration and mass of the currently measured calibration weight
6.1.6.
dSh
Dashed line separating printout data and signature fields
6.1.7.
SiG
An area for the signature of an operator carrying out the calibration
Figure 10. Calibration report example
8.2 GLP printout
<P6.2.GLP> is a group of parameters allowing to declare variables that are to be printed on a
weighing printout. Each variable allows for accessibility attribute: YES – print, no – do not print.
Table 7. GLP weighing printout variable list
Submenu Name Description
6.2.1.
dAt
Weighing date
6.2.2.
tin
Weighing time
6.2.3.
n
Net weight value of performed weighing in a basic measuring unit
6.2.4.
t
Tare weight value in a current unit
6.2.5.
b
Gross weight value in a current unit
6.2.6.
CrS
Current weighing result (net weight) in a current unit
6.2.7. CrP
The last adjustment report generated in accordance with settings declared for the
adjustment report printout
