ResMed S9 Series Clinical Guide

29
English
S9 technical specifications
Operating pressure range 4 to 20 cm H
2
O
Maximum single fault steady
state pressure
30 cm H
2
O if pressure exceeded for >6 sec
40 cm H
2
O if pressure exceeded for >1 sec
Pressure measurement
tolerance
±0.5 cm H
2
O ± 4% of the measured reading
Flow measurement tolerance ±6 L/min or 10% of reading, whichever is greater, at 0 to 150L/min
positive flow
DECLARED DUAL-NUMBER NOISE EMISSION VALUES in accordance with ISO 4871:1996
Sound pressure level
with SlimLine tube:
with Standard tube:
with either SlimLine tube or
Standard tube and H5i:
24 dBA as measured according to ISO 17510-1:2002
26 dBA with uncertainty of 2 dBA as measured according to
ISO17510-1:2007
24 dBA as measured according to ISO 17510-1:2002
27 dBA with uncertainty of 2 dBA as measured according to
ISO17510-1:2007
27 dBA as measured according to ISO 17510-1:2002
28 dBA with uncertainty of 2 dBA as measured according to
ISO17510-1:2007
Sound power level
with SlimLine tube:
with Standard tube:
with either SlimLine tube or
Standard tube and H5i:
34 dBA with uncertainty of 2 dBA as measured according to
ISO17510-1:2007
35 dBA with uncertainty of 2 dBA as measured according to
ISO17510-1:2007
36 dBA with uncertainty of 2 dBA as measured according to
ISO17510-1:2007
Nominal dimensions
(L x W x H)
6.0” x 5.5” x 3.4” (153 mm x 140 mm x 86 mm)
Weight 1.84 lb (835 g)
Housing construction Flame retardant engineering thermoplastic
Supplemental oxygen Recommended maximum supplemental oxygen flow: 4 L/min
Air filter
Standard:
Hypoallergenic:
Polyester non-woven fiber
Acrylic and polypropylene fibers in a polypropylene carrier
Air outlet The 22 mm conical air outlet complies with ISO 5356-1:2004
H5i technical specifications
Maximum heater plate
temperature
150°F (65°C)
Temperature cut-out 165°F (74°C)
Maximum gas temperature
at mask
≤ 106°F (≤ 41°C)
Nominal dimensions
(L x W x H)
Docking station and water tub: 6.0” x 5.7” x 3.4”
(153 mm x 145 mm x 86 mm)
Weight (water tub) Docking station and unfilled water tub 1.5 lb (0.67 kg)
Weight (cleanable water tub) Docking station and unfilled water tub 1.7 lb (0.77 kg)
Water capacity To maximum fill line 380 mL
Docking station Flame retardant engineering thermoplastic, aluminium
Cleanable water tub Injection molded plastic, stainless steel and silicone seal
Water tub Injection molded plastic, aluminium and elastomer seal
368220.indb 29 6/09/2011 9:22:28 AM

ResMed S9 Series Specifications

General

Data Storage	SD card
Device Type	CPAP Machine
Pressure Range	4 to 20 cm H2O
Sound Level	24 dB
Power Supply	100-240V AC, 50/60Hz
Therapy Modes	CPAP, VPAP ST, VPAP Auto
Altitude Adjustment	Yes
Operating Temperature	+41°F to +95°F (+5°C to +35°C)
Operating Humidity	10% to 95% non-condensing
AC Voltage	100-240V AC
Humidifier	optional
Ramp	Yes
