Resol DeltaSol E - Page 20

relay allocation
sensor allocation
sen.1 sen.2 Sen.3 sen.4 sen.5 sen.6 sen.7 sen.8 sen.9 sen.10 V40
Tcol
Tstb
HSE
Tby Tst2b
Th 5
T1-DT7
Tcol2
Th 6
T2-DT7
Th 7
T1-DT8
Th 8
T2-DT8
Th 9
T1-DT9
T1 WMZ
Th 10
T2-DT9
T2 WMZ
WMZ
relay 1 relay 2 relay 3 relay 4 relay 5 relay 6 relay 7
2-PV col. 1 2-PV col.2 solar pump st 1 solar pump st 2
func. bl. 3
HSE
bypass
par. relay
func. bl. 4
store load.
func. bl. 5
message rel.
AH suppress.
System 4 variant 3
relay allocation
sensor allocation
sen.1 sen.2 sen.3 sen.4 sen.5 sen.6 sen.7 sen.8 sen.9 sen.10 V40
Tcol
Tstb
HSE
Tby Tst2b
Th 5
T1-DT7
Tcol2
Th 6
T2-DT7
Th 7
T1-DT8
Th 8
T2-DT8
Th 9
T1-DT9
T1 WMZ
Th 10
T2-DT9
T2 WMZ
WMZ
relay 1 relay 2 relay 3 relay 4 relay 5 relay 6 relay 7
2-PV Kol. 1 2-PV Kol.2 solar pump 3 PV store 1-2
func. bl. 3
HSE
bypass
par. relay
func. bl. 4
store load.
func. bl. 5
message rel.
AH suppress.
System 4 variant 4
S1
S6
R1
R2
S2
S4
R3
R4
S1 S6
R1 R2
S2
S4
R3
R4
DeltaSol
®
E
