Resol DeltaSol E - Page 21

relay allocation
sensor allocation
sen.1 sen.2 sen.3 sen.4 sen.5 sen.6 sen.7 sen.8 sen.9 sen.10 V40
Tcol
Tstb
HSE
Th 1
Tby
T-HE
T1-DT5
Th 2
Tst2b
T2-DT5
Tst3b ---
Th 7
T1-DT8
Th 8
T2-DT8
Th 9
T1-DT9
T1 WMZ
Th 10
T2-DT9
T2 WMZ
WMZ
relay 1 relay 2 relay 3 relay 4 relay 5 relay6 relay 7
solar pump
2 PV store 1
(3PV store 1)
func. bl. 1
ext. HE
2 PV store 2
(3PV store 2)
2 PV store 3
(---)
func. bl. 4
store load.
HSE
bypass
par. relay
func. bl. 5
message rel.
AH suppress.
System 5 variant 1
S5
R1
R2
S2
S4
R4 R5
S1
S1
R1
R2
R4
S2
S4 S5
relay allocation
sensor allocation
sen.1 sen.2 sen.3 sen.4 sen.5 sen.6 sen.7 sen.8 sen.9 sen.10 V40
Tcol
Tstb
HSE
Th 1
Tby
T-HE
T1-DT5
Th 2
Tst2b
T2-DT5
Th 5
Tst3b
T1-DT7
Th 6
T2-DT7
Th 7
T1-DT8
Th 8
T2-DT8
Th 9
T1-DT9
T1 WMZ
Th 10
T2-DT9
T2 WMZ
WMZ
relay 1 relay 2 relay 3 relay 4 relay 5 relay 6 relay 7
solar pump st1 solar pump st2
func. bl. 1
ext. HE
solar pump st 3 func. bl. 3
func. bl. 4
store load.
HSE
bypass
par. relay
func. bl. 5
message rel.
AH suppress.
System 5 variant 2
S1
S5
R1
S2 S4
R2
R4
DeltaSol
®
E
