5 Status level / Measurement values
During normal operation of the controller, the display is in the status level, indicating
the measurement values (depending on the system) shown in the table.
In addition to the display values, possible error messages are indicated in the status
menu (see page 51).
Display Description (long text)
TCOL Temperature collector
TCOL2 Temperature collector 2
TSTB Temperature store base
TSTT Temperature store top
TST2B Temperature store 2 base
TSTTS Temperature heat exchange source
TST2S Temperature heat exchange sink
TAH Temperature afterheating
TSFB Temperature solid fuel boiler
TSTSF Temperature store - solid fuel boiler
TSTRP Temperature store return preheating
TRET Temperature heating circuit return
S3 Temperature sensor 3
S4 Temperature sensor 4
n1 % Speed relay 1
n2 % Speed relay 2
L/h Flow rate sensor V40
TFHQM Heat quantity measurement ow temperature
TRHQM Heat quantity measurement return temperature
kWh Heat quantity in kWh
MWh Heat quantity in MWh
BLPR Blocking protection relay 1
BLPR2 Blocking protection relay 2
INIT Initialisation drainback
FLLT Filling time drainback
STAB Stabilisation drainback
TDIS Disinfection temperature
CDIS Countdown thermal disinfection
DDIS Disinfection period
SDIS Starting time delay
TIME
DATE
6 Balance values
The balance value menu indicates the balance values.
Display Description
h R1 Operating hours relay 1
h R2 Operating hours relay 2
h R4 Operating hours relay 4
DAYS Operating days of the controller (cannot be set back to zero)
MAXS1 Maximum temperature sensor 1
MINS1 Minimum temperature sensor 1
MAXS2 Maximum temperature sensor 2
MINS2 Minimum temperature sensor 2
MAXS3 Maximum temperature sensor 3
MINS3 Minimum temperature sensor 3
MAXS4 Maximum temperature sensor 4
MINS4 Minimum temperature sensor 4
