19
OHQM 19
PUSH
FMAX
Flow rate in l/min
Adjustment range: 0.5 … 100.0
in steps of 0.1
Factory setting: 6.0
MEDT
Heat transfer uid
Adjustment range: 0 … 3
Factory setting: 3
SFHQM
Flow sensor
Adjustment range: 1, 3, 4
Factory setting: 1 / 3
MED%
Antifreeze concentration in vol. %
(MED% will not be displayed
when MEDT 0 or 3 is used)
Adjustment range: 20 … 70 %
in steps of in 1 %
Factory setting: 45 %
SRHQM
Return sensor
Adjustment range: 2, 3, 4
Factory setting: 2 / 4
FTYPE
Flow rate detection type:
Selection: 1, 2
Factory setting: 1
OHQM
Heat quantity measurement option
Adjustment range: OFF / ON
Factory setting: OFF
19
Heat quantity measurement
The heat quantity measurement can be carried out in 2 different ways: without V40
owmeter or with V40 owmeter
Note
The most precise heat quantity measurement is achieved by using sensors
in the ow and return pipes as well as a owmeter.
In 2-collector systems, heat quantity measurement can only be carried out
with sensors installed in the common ow and return pipes.
Flow
sensor
V40 /
owmeter
Return sensor
Example of ow and return sensor positions for heat quantity measurement.
Î Enable the heat quantity measurement option in the channel OHQM.
Î Select the type of ow rate detection in the channel FTYPE.
Flow rate detection type:
1 : Fixed ow rate value (owmeter)
2 : V40
Note
If the ow rate detection type V40 has been adjusted,the impulse rate of
the sensor must be adjusted in the SENS menu (see page 47).
Note
If a V40 is used as the ow rate sensor (ow rate detection type 2) and is
then deactivated in the SENS menu, the ow rate detection type will be
set to 1 (owmeter) and heat quantity measurement will be deactivated.
OFF ON
