Resol DeltaSol SLL User Manual

en
33
InstallationIndications, functions and optionsMessages Commissioning Operation and function
3/4
Priority logic
Priority logic can be used in 2-store systems or systems with store loading in layers
only and determines how the heat is divided between the stores.
PRIO: Store 1 / store base
PRIO2: Store 2 / store top
The store which has been adjusted to 1 is considered as the priority store.
If both stores have been adjusted to an identical value, they will be loaded in parallel.
Store maximum temperature and Sensor store maximum temperature
If the store temperature reaches the adjusted maximum temperature, the store
will no longer be loaded in order to avoid damage caused by overheating. If the
maximum store temperature is exceeded, ☼ is displayed.
The sensor for store maximum limitation can be selected. The maximum limitation
always refers to the sensor selected.
The switch-on hysteresis is selectable.
Note
In systems with 2 stores or store loading in layers, 2 separate menus
(LOAD and LOAD 2) will be displayed.
Loading store
In systems with 2 stores or store loading in layers, one of the two stores or the
store zone respectively can be switched off with the parameter LST(2).
If LST or LST2 is adjusted to OFF, the system runs like a 1-store system. The
representation in the display remains the same.
PRIO (2)
Priority logic
Selection: 1, 2
Factory setting: 1
S(2)MAX
Store maximum temperature
Adjustment range: 4 … 95 °C
in steps of 1 °C
Factory setting: 60 °C
S(2)MAXS
Sensor store maximum temp.
Adjustment range:
1-store system: S2, S3
2-store system: S4, S5
Factory setting:
1-store system S2
2-store system: S4
LST (2)
Loading store 1, 2
Selection: ON / OFF
Factory setting: ON
RIS (2)
Rise
Adjustment range: 1 … 20 K
in steps of 1 K
Factory setting: 2 K
a c
BACK
PUSH
3/4
5/6
b
