Response Biomedical RAMP READER - Set Master P.I.N; Setting the System Clock

RAMP® System Operation
Operator’s Manual, RAMP
®
Reader 27
NOTE: Please contact Technical Support (Appendix ). Be sure the Reader is accessible
and the screen with the permit # (above) is visible. An override code will be provided by
Technical Support.
Press [Enter] to enter the override code.
NOTE: Entering the override code does not reset the Master P.I.N. but allows immediate
access to the SYSTEM SETTINGS menu where the Master P.I.N. can be reset.
If the Master P.I.N. is not enabled, all operators will have access to the SYSTEM SETTINGS menu.
2.6.2 Set Master P.I.N.
The Reader can be set such that system settings or stored results are protected from unauthorized
change or deletion. From RUN/OPTIONS Menu, select Options and then press [▲] or [▼] until 5.
SYSTEM SETTINGS is displayed. Press [Enter] to access the SYSTEM Menu. Press [Enter] at the
screen to select 1. SET MASTER P.I.N.
The current P.I.N. is displayed in the first line. If the Master P.I.N. has not been set, “00000” is
displayed. The second line prompts the operator to enter a new P.I.N.
Using the keypad, type in a new P.I.N. (the P.I.N. can be from 1 – 5 digits). Press [Enter] to accept
and reset the P.I.N.
NOTE: To disable the Master P.I.N., set the Master P.I.N. to “00000”.
2.6.3 Setting the System Clock
The clock displays a 24-hour format. From the SYSTEM Menu, press [▲] or [▼] until 2. SET CLOCK
is displayed. Press [Enter] to select this option. The following prompt is displayed:
The arrows surrounding a field indicate the active edit field. To edit the active field, press [▲] or [▼]
until the proper value is displayed. When the value is correct, press [Options] to move the editor to
the next field. When finished, press [Enter] to return to the SYSTEM Menu.
DATE:►2015◄ APR 19
TIME: 11 : 55
EDIT P.I.N.: 12345
_ ***************
ENTER OVERRIDE CODE:
_ *************
