5.0 READER SPECIFICATIONS
Dimensions
27 cm wide x 25 cm deep x 15 cm high
(10 ½ in wide x 10 in deep x 6 in high)
Weight
2.1 kg (4.6 lbs)
Reader
Power Requirements
15 – 18 Vdc, 1A Max
Power Supply Output
Power Supply Input
Pollution Degree
18 Vdc, 0.84A
100-240 Vac, 47-63 Hz
2
Installation Category
II
RAMP
®
Battery
Rechargeable
Internal; not operator serviceable
External Connections
RS-232 DB-9 (male), for serial communication
Proprietary Mini DIN for barcode wand
Operating Temperature Range
5 – 40°C (41 – 104°F)
Note 1
Operating Humidity Range
20 – 80% relative humidity, non-condensing
Storage
/Transport
Humidity Range
20 – 90% relative humidity, non-condensing
Storage
/Transport
Temperature
Range
-10 - 50ºC (14 - 122ºF)
Operating/Storage Altitude
<2000m
Keypad
10 character alphanumeric keys plus
2 special function keys
Display
2 line by 20 character Liquid Crystal Display (LCD)
Complies With
IEC 61010-1: Safety requirements for electrical equipment for
measurement, control, and laboratory use
IEC61010-2-101-04: Particular requirements for in vitro diagnostic
(IVD) medical equipment
IEC 61326-1: Electrical equipment for measurement, control and
laboratory use – EMC requirements
FCC 47 CFR Part 15/B
Note
2
Noise Level
Does not emit sound level greater than 85 dB when
running an assay.
NOTE 1: Refers to Reader only. Please refer to specific assay temperature specification when
running assays.
