Retsch GM 200 - Powering On;Off and Hood Operation; Hood Closing Hazard

Operating the Device
25
Element
Description
Function
B
Control element with knob
For operating the machine
C
Grinding jar
Container for the sample material
D
Lid on the grinding jar
Seals the grinding jar
F
Hood
Closes the machine
G
Air vents
For exhaust air from the motor and inside of
the machine
H
Housing fan
Fan for waste heat
I
On/off switch
Switches the machine on and off,
disconnects the machine from the mains
J
Mains connection
Connection for the power cable
K
USB interface
Data connection
L
Warning sign "Pull out the plug "
Warns about the risk of an electric shock
M
Type plate
Lists the voltage version, serial number and
model among other things
N
“Manual” sticker
Draws attention to reading the manual
O
Interface for the Wi-Fi connection
(RPIO)
Data connection for connecting Wi-Fi to the
Retschbox (optional accessory)
P
Rubber coupling for the
Retschbox
For securing the Retschbox
6.3 Switching On / Off
 Turn on the GM 200 with the mains switch (I) on the back side of the device.
When the device is switched off, it is completely disconnected from the mains.
6.4 Opening and Closing of the Device
6.4.1 Opening
 Connect the device to the mains.
 Switch the device on by means of the mains switch (I).
 Press the button (B3.1). The locking mechanism is released and the hood opens.
6.4.2 Closing
CAUTION
C10.0008
Risk of pinching and bruising
Device hood closing
 The device hood can trap fingers when closing, thereby causing pinching
or bruising.
 Never allow the device hood to close by itself.
 Always hold the device hood firmly when closing it.
 Press the hood (F) downwards. The locking mechanism (A) locks automatically.
