Fig. 6: Inserting the filled grinding container with the standard lid (left) and the reduction lid (right)
NOTICE With the reduction lid, the pressing down is absolutely necessary to have the knife
insert reaching its end position and locking into place. Do not use the gravity lid when filling the
grinding container outside the device, since the knife insert in combination with the gravity lid
will not lock during insertion!
Close the hood (F).
6.8 Closing the Grinding Container
Fig. 7: Closing the grinding container with the standard lid
The standard lid (SD) fits all available grinding containers. The standard lid is clamped on the
edge of the container and can be released again with the lug (LA).
Press the standard lid (SD) from the top diagonally across the opening of the grinding
container (MB).
Check the tight clamping of the standard lid on the grinding container.
For the GM 200 various lids are available from the Retsch GmbH. The different lid-grinding
container combinations allow for an optimum adjustment to the individual tasks.
