Revolectrix GT1000 User Manual

16
Example 2: Charging a LiPo pack
1. Connect GT1000 to a 10–32V DC power supply or 12–28.8V battery. When
powered on, the Revolectrix logo screen will display briefly or remain on
indefinitely depending on the Logo Display option setting defined in
CHEMISTRY/SETTINGS -> SETTINGS -> VISUAL SETTINGS. If the logo has
not been set to On, skip to step 3.
2. Press any button or turn the navigation wheel to exit the Revolectrix logo
screen.
3. If the Pwr On Default option has not been set to Select, skip to step 4.
Otherwise, the SELECT POWER SUPPLY menu will appear. Then:
a. Turn the navigation wheel to select one of the power source that matches
the power supply you’re using.
b. Press ENTER.
4. If you are using GT1000 for the first time, the CHEMISTRY/SETTINGS menu
will appear next.
5. Connect the LiPo pack to GT1000:
a. Connect the balance connector of the LiPo pack to GT1000. (See
Connecting Packs for details.)
b. Connect the banana jack cable between the pack/battery and the
GT1000.
6. In the CHEMISTRY/SETTINGS menu:
a. Use the navigation wheel to scroll to the Lithium-Po/FePO4 option if it’s
not already highlighted. This option in general applies to all Lithium
battery chemistries available.
b. Press ENTER.
7. In the next screen, the header displays LITHIUM-PO/FEPO4 to indicate you
have selected this chemistry. Use the navigation wheel to scroll to Charge
mode if it’s not already highlighted and press ENTER.
8. In the next screen, the header displays LI-PO/FEPO4-CHARGE to indicate the
battery chemistry and the operating mode you have selected above. The next
few lines display the basic settings/options applicable to the LiPo charge
Tip: The following detailed instructions for charging a LiPo pack will
help you learn how to navigate through the charging process. Once
you become familiar with GT1000 operations, you shouldn’t need
instructions at all.
IMPORTANT: To prevent damage to the power source, you must
specify the power source’s operating characteristics before charging
for the first time with a DC power supply, and before charging for the
first time from a battery. The GT1000 allows you to store up to 6
different power supply profiles (3x DC power supply profiles and 3x
Lead Acid battery profiles). After that, load the power supply profile
using the Power Source option any time you change to a different DC
power supply or battery.
