10
1. Strap the dash cam to the rearview mirror of your vehicle with the rubber
mounting strap. Adjust the angle of the cameras to ensure that it
captures your desired view.
2. Mount the rear camera as shown below and then connect the rear
camera to the main unit. Carefully route the power cable around the
door and tuck in under the trim.
The rearview camera has two wire routing options as shown in the above
figure. The first part of both options is characterized with concealing the
wire routing against the edges of the door(s).
The device is configured with a streaming media rearview camera that
provides clear trac view behind the car. To obtain clearer and more
intuitive images, it is recommended to mount the camera above the
license plate (as shown by option B).
Installation
Rear camera wiring options
Connected to the reversing light
Dash Cam Installation
