10
Note: This number will automatically be generated as a result of the weight / rev. calibration process
(AUTOCAL) or you can input this value manually.
7.5 CAL GATE
Enter the correct gate setting at which the current solid material was calibrated at.
7.6 AUTOCAL
Here is where you can perform the material calibration if the controller is set to ‘Auto’ or ‘Open’
1. Place an adequate catch container under the spreader discharge chute.
2. Make sure that you have sufficient material in the hopper, ensure the conveyor or auger has been
loaded, hopper is full of material and the system is safe to run.
3. Set the gate position. (ensure you enter this value in the CAL GATE field)
4. Press ENTER to proceed.
5. Turn the CONV knob to any position to start the material discharging.
6. Press FINSH when the desired amount of material is reached.
After pressing FINSH, the screen will jump to the material weight input screen, enter the weight of the material
that was dispensed, the controller will calculate the WT/REV and the result will be displayed on the screen.
CONVEYOR 1 SALT
MODE: AUTO BLAST: 0270 M99%
SENSOR: 0050 RATE1: 0032
NULL: 15.0 60.0 WT/REV: 1.00
GAIN: 60% CAL GATE: 05
AUTONULL * AUTOCAL
CONVEYOR 1 SALT
MODE: AUTO Measure material
SENSOR: 0050 Enter Number
NULL: 15.0 60.0 Wgt: 0000
GAIN: 60%
AUTONULL * AUTOCAL
