REXROTH HCS03 User Manual

Risk of damage to the drive controller by con‐
necting and disconnecting live connections!
NOTICE
Do not connect and disconnect live connections.
5.3.2 Sizing of Enclosure and Control Cabinet
Multiple-Line Design of the Control Cabinet
Arrangement of the devices, air guides/drip protections, fans
Pay particular attention to the maximum allowed air intake tem‐
perature of devices when they are arranged in multiple lines in the
control cabinet.
If possible, place devices with a high degree of power dissipation
(e.g. supply units with braking resistors, DC bus resistor units)
● in the top line and
● near the outlet air aperture to the cooling unit
Mount air guides between the lines to
● protect the devices in the upper lines against the warm outlet
air of the devices beneath and
● protect the devices beneath against penetration of liquids
(e.g. dripping condensation water or leaking cooling liquid)
Additional fans convey the outlet air to the cooling unit and cool‐
ing air to the upper lines.
At the installed control cabinet, check the air intake temperature
of all devices.
To extend the module bus connection, the accessory RKB0001 is
available. Observe the assignment.
DOK-INDRV*-HCS03******-IT01-EN-P
Rexroth IndraDrive Drive Controllers Power Sections HCS03
Bosch Rexroth AG 45/67
Instructions for Use
