2020 rf IDEAS Inc rfIDEAS Configuration Utility User Manual P a g e 56
FIELD/BUTTON DESCRIPTION
Card Type Card type matches are displayed here
Supporting
Readers
Displays the supported rf IDEAS readers when a card type is selected
Start Scan Start the scan function
Halt Scan
Stop the scan This button becomes active after the Start Scan
button is pressed and the scanning starts
Auto Config
Takes the user to the Auto Config screen This screen allows the user
to configure the reader using the default Card Type settings
Exit Returns user back to main Card Analyzer window
Every time the Start Scan button is pressed the application scans for the
Contactless 1356 MHz and Proximity 125 KHz Card Types
To learn a card:
The application saves the current reader settings prior to scanning They are
restored if the user exits without writing the discovered settings
1 Click the Start Scan button The Popup Window appears
