2020 rf IDEAS Inc rfIDEAS Configuration Utility User Manual P a g e 61
It is not possible to jump directly to the Auto Config feature without first
performing the Learn Card feature
For some cases Auto Config button may be disabled based on reader type or
scanned card type
FIELD/BUTTON DESCRIPTION
Card ID Contains the Card ID based on the default settings for the selected
Card Type
Card Type
When the user selects a Card Type the application displays the Card
ID based on the most popular default settings for the selected card
type
Configuration#
Write multiple configurations to the reader by selecting the
configuration from the dropdown and clicking the Write button
Write
Writes the configuration to the reader for the selected card type
Writing one of the scanned cards from card type list into reader will
enable Save Hwg File button
Learn Card Go back to the Learn Card screen
Analyze Move to the Analyze Card screen
Exit This button has the following functions
x
If the user has not written any configurations pressing the
Exit button will restore the reader to its original settings prior
to starting the Card Analyzer Then returns the user to main
Card Analyzer window
x
If the user has written configurations pressing the Exit
button will return user to main Card Analyzer window with the
new card settings
To auto configure:
1 Select each card type and match the Card ID listed with the ID on the card
