4.10 CHAMBER
The chamber utilizes a robust design, with a cable management
system for the chamber temperature probe, sample gas injection
to center of chamber, local pressure measurement, an optional
heat dispersion plate, and a shelving system. It is equipped with
comprehensive heat insulation in all sides and doors of the test
chamber and features sealed edges with a soft silicone profile seal
for gas tightness.
An integrated fan with control provides internal air circulation and
ensures uniformity and stability throughout the chamber. The
chamber design features a false wall for a fully air-jacketed
approach. The air-jacket is encased within a fluid jacket to ensure
unparalleled stability. The inside of the temperature chamber for
demanding temperature simulations is constructed from stainless
steel.
