7.2 TROUBLESHOOTING
7.2.1 ERROR CODES
There are two types of error conditions in the system: emergency shutdown (ESD) conditions and warnings. An
ESD will show red in RHS Control and shut the machine down. A warning will show up as yellow in RHS Control and
will not influence the machine's running. If warning or errors persist after you’ve performed the resolution,
perform full power cycle before contacting the Support team at RH Systems (support@rhs.com).
EMERGENCY SHUTDOWN CODES
DESCRIPTION
RESOLUTION
6
[Pl/Ph] Bad pressure Sensor
Calibration
The difference between the high
range and low range pressure
sensors is too high.
Pressure sensors need
recalibration.
Faulty Saturator/Chamber
select solenoids (SOL4 &
SOL5) (see section 6.2.7).
17
[Tp] Presat Temperature
Missing
Presat temperature sensor is not
reading and is possibly
disconnected.
Check pre saturator
temperature sensor (Ch1)
connection or check
temperature measurement
board (see section 6.7 or
6.1.3).
18
[TS] Sat Temperature Missing
Sat temperature sensor is not
reading and is possibly
disconnected.
Check saturator
temperature sensor (Ch2)
connection or check
temperature measurement
board (see section 6.7 or
6.1.3).
19
[Tev] Expansion Valve
Temperature Missing
Expansion valve temperature
sensor is not reading and is possibly
disconnected.
Check expansion valve
temperature sensor (Ch5)
connection or check
temperature measurement
board (see section 6.7 or
6.1.3).
20
[Tcl] Chamber Liquid
Temperature Missing
Chamber liquid temperature sensor
is not reading and is possibly
disconnected.
Check chamber liquid
temperature sensor (Ch4)
connection or check
temperature measurement
board (see section 6.7 or
6.1.3).
