6.6 CONNECTIONS TO THE ECB
The Embedded Controller Board (ECB) has many different inputs and outputs used to operate the system. Grouped
by functional type, the following tables in this chapter list the various inputs and outputs of the ECB and reference
the specific sections of this manual where each input or output is discussed.
Figure 6.34
