RH CGS-240 - Door

Operation
CGS-240 Manual 6/15/2021
Page 35 of 148
4.11 DOOR
The liquid jacketed chamber door uses heavy duty hinges, a recessed latching mechanism, a built-in light, and
built-in heaters for the door frame and window. The liquid jacketing of the door and window aid significantly in the
chamber stabilization and temperature uniformity.
Figure 4.27
Figure 4.28
