Illustrated Parts Breakdown
CGS-240 Manual 6/15/2021
Page 95 of 148
SS, M4 x 0.70 mm Thread, 22mm Long
Nema 17 Rotary Valve Optic Holder
External Retaining Ring for 15 mm OD, Black-
Phosphate 1060-1090 Spring Steel, 1mm thick
Ball Bearing, Sealed, Trade No. 6802-2RS, for
15 mm Shaft Diameter
Nema 17 Rotary Valve Plug
Chemical-Resistant Viton O-Ring, 3/32
Fractional Width, Dash Number 115
Chemical-Resistant Viton O-Ring, 1/8 Fractional
Width, Dash Number 210
Neam 17 Rotary Valve Body
Button Head Hex Drive Screw, Passivated 18-8
SS, M3 x 0.50 mm Thread, 50mm Long
Chemical-Resistant Viton O-Ring, 1/16
Fractional Width, Dash Number 016
Nema 17 rotary valve face seal
Button Head Hex Drive Screw, Passivated 18-8
SS, M4 x 0.70 mm Thread, 10mm Long
REDUX Wave Spring, 0.75"OD, 0.55"ID, 0.25"
Free Length, 272 lb/inch spring rate
Optical Switch, Panel / Chassis, 3.81 mm, 1.52
mm, 50 mA, 2V
Button Head Hex Drive Screw, Passivated 18-8
SS, M2.5 x 0.45 mm Thread, 6mm Long
18-8 Stainless Steel Cup-Point Set Screw, M4 x
0.7 mm Thread, 5 mm Long
Alloy Steel Cup-Point Set Screw, Black-Oxide,
2-56 Thread, 5/8" Long
Fuse modular terminal block - UT 4-L/HESI
(5X20)
SSR RELAY SPST-NO 3A 1-60V
Modular terminal block - UT 2,5-PE/L/L
Solid State Relays - Industrial Mount DIN SSR
280VAC/30A 4.5-32VDC In,ZC
Solid State Relays - Industrial Mount DIN SSR
280VAC/20A 4.5-32VDC In,ZC
Solid State Relays - Industrial Mount DIN SSR
280VAC/10A 4.5-32VAC In,ZC
DIN Rail Power Supplies 60W 12V 5A 180-
550Vin DIN
DIN Rail Power Supplies 10W 5V 2A
Ground modular terminal block - UT 6-PE
