Duplex
A896
COVER REMOVAL
SM 13-9 A265/A267
3. REPLACEMENT AND ADJUSTMENT
3.1 COVER REMOVAL
1. Remove the duplex unit cover [A] (4 screws).
A896R501.WMF
[A]
