ISDN Unit
A895
INSTALLATION PROCEDURE
SM 1-1 A265/A267
1. INSTALLATION
1.1 INSTALLATION PROCEDURE
!
CAUTION
Before installing this option, do the following:
1. Print out all messages stored in the memory, the lists of user-
programmed items, and the system parameter list.
2. If there is a printer option in the machine, print out all data in the printer
buffer.
3. Turn off the main switch and disconnect the power cord, the telephone
line, and the LAN cable.
1. Remove the small cover [A] (1 rivet) and the rear cover [B] (4 screws). Then cut
away the jack window [C].
2. Remove the NCU unit [D] (4 screws, 2 connectors)
A895I352.WMF
A895I310.WMF
[A]
[B]
[C]
[D]
To Next Page
