Jam 11 Registration Late Jam: Duplex Unit
Message
Paper Misfeeed
Press the Form Feed button.
Cause
• Paper feed rollers slipped, could not feed paper
•
Paper caught, warped in paper feed path.
Details
After the paper fed from the tray, or when the paper was inverted for duplexing, after
the trailing edge sensor went ON, the registration sensor failed to detect within the
prescribed time.
Action 1
• Press [Form Feed] key on operation panel.
Action 2
• Replace inverter guide.
• Replace trailing edge sensor.
•
Replace CTL board.
Jam 12 Not Used
Jam 13 Not Used
Jam 14 Carriage Jam
Message
Paper Misfeed
Open the Top Cover and press the Form Feed key to remove the paper.
If this does not work or pieces of paper still remain then manually remove it from the
top of the machine.
Also check paper is set correctly in all the paper source trays
Cause The carriage failed to reach its target position within the prescribed time.
Details An obstruction is blocking movement of the carriage unit.
Action 1
• Open the top cover.
• Turn the paper feed wheel on the left side of the printer to feed out any remaining
paper.
•
Check around the carriage unit for paper scraps or any other type of obstruction.
• Make sure that the paper cassette and bypass tray are set correctly.
Error Codes
103
