SH-P1 Training
109
Slide 109
2. Energy Saving
2.2 Energy Saver Mode: Sleep Mode – 2
The machine recovers to the ready condition:
If data is received
» After warm-up, the job starts, but the operation panel stays
dark.
» Then, after the job is completed, the machine returns to sleep
mode immediately. Panel Off and Low Power modes are
skipped.
Power
Consumption
Warm-up
Operation Mode
Ready Mode
Sleep Mode
Plug In
Time
Data is received
Warm-up
Operation Mode
Sleep Mode
This timing chart shows what happens if data is received while the machine is in
sleep mode.
Power consumption during warm-up may be much higher than shown in this
diagram.
