1. Open the bypass tray.

BMW072S

2. If you load paper longer than A4 , pull out the bypass tray extension.

BEK014S

3. Slide the side guides outward ( ), and then load paper with the print side down ( ), flush

against the printer.

BEK015S

4. Adjust the side guides to fit the paper width.

Paper capacity of the bypass tray differs between plain and thick paper. Check the limit marks on the

paper guide of the bypass tray.

Loading Paper

129
